With a heating capacity of 2Kw and 4KW, it provides great comfort, safety, reliability
and heating capacity for large commercial vehicles.
Quick, easy installation and low maintenance costs make it an economical retrofit solution!
Model | WH-02 | WH-04 |
Fuel Type | Diesel, Biodiesel | Diesel, Biodiesel |
Working Voltage | DC 12V/DC24V | DC 12V/DC24V |
Heat Carrier | Air | Air |
Heat Flow Mode | Automatically /manually | Automatically /manually |
Heating Capacity | 2000W | 4000W |
Power consume | 4-34W | 7-33W |
Fuel Consumption | 0.10~0.28L/H | 0.15~0.48L/H |
Working Temperature | -40 ℃ ~ + 50 ℃ | -40 ℃ ~ + 50 ℃ |
Heating air Volume |
40~105m3/h |
60~185m3/h |
Weight | 2.8kg | 4.1kg |
Diamension | 383*275 * 200mm | 505*487*325mm |
Noise level (interior) | Maximum sound pressure <60db(A) | Maximum sound pressure <60db(A) |
