Superway Pantograph System ESS 215kWh

Superway Pantograph System ESS 215kWh

 Utilize High-End Components
 Design Life ≥ 10 Years
Utilize Automotive-Grade Lithium Iron Phosphate Battery
Battery Pack Temperature and Voltage Control
Liquid Cooling Battery Array
30 Active Safety Checks
Power Conversion Efficiency: >95%

  • Bus Station

  • Railway station

  • Public Parking

  • Shopping mall

Superway Pantograph System ESS 215kWh

In the new energy era, charging piles must not only charge efficiently, but also be durable, safe and stable. Superway charging piles are designed with high-end components, with a service life of ≥10 years, and are equipped with 30 active safety checks. At the same time, they have a power conversion efficiency of >95%, providing charging station operators and new energy vehicle owners with a more reliable, efficient and safer charging solution!

Superway Pantograph System Features

⚡ 10-year long life, stable and durable

Superway charging piles use high-end industrial-grade components with super durability and anti-aging performance. They can operate stably for a long time and have a service life of ≥10 years, which greatly reduces maintenance costs and makes the return on investment of charging stations more lasting.


⚡ 30 active safety inspections, all-round protection

Charging safety is crucial. Superway charging piles are equipped with 30 active safety detection mechanisms to monitor key safety indicators such as current, voltage, temperature, short circuit, overload, etc. in real time, effectively prevent safety hazards, and ensure that the charging process is stable and reliable.


⚡ >95% power conversion rate, energy saving and more efficient

Using advanced power management systems, Superway charging piles achieve **>95% ultra-high power conversion efficiency**, reduce power loss, improve the overall efficiency of charging stations, reduce operating costs, and maximize the value of every kilowatt-hour of electricity.


⚡Applicable to all kinds of charging scenarios

★Public charging stations: efficient and stable, reducing maintenance costs
★Shopping malls/office buildings: intelligent and safe, meeting high-end charging needs
★High-speed service areas: efficient and fast charging, supporting long-distance travel
★Commercial logistics fleets: durable and long-lasting, reducing operating costs



Technical Specification



Battery power 215kWh
Voltage range 600-876VDC
Input power rating AC380/Max 40KW/80KW
Battery cycling ≥6000 Cycles
Cooling system Liquid
Output current 140A
Output power 107KW
Max output power 120KW+40KW/80KW
Output voltage 200V-1000VDC
Output current 250A（max）
Cooling system Fan
Charging connector 2
Interface 7” LCD touchscreen
Communication protocols OCPP 1.6J（Extendable to ocpp 2.0）
Operation tips Voice function
Advertising screen 15.6” inches
Payment system RFID, QR code, APP and POS etc.
Software update Remote upgrade
Communication system 4G, WIFI, Bluetooth, Ethernet
Dimensions(W*D*H) 2000*1300*2100
Noise Control <65dB
Operational altitude Up to 2500 m
Operating temperature range -30°C to + 55°C (power de - rating applies)
Humidity 5 -95% Rh non- condensing
IP and IK rating IP-54(Battery pack IP65) and IK-10(cabinet)/IK-8(touchscreen)
Cable length 5 meters(8m/10m optional)
Certification Battery cells：IEC 62619/IEC62933/UN38.3
Battery system：IEC 62619， IEC 63056 and IEC62477-1
Charging：IEC 62619, IEC61851, IEC62477, IEC15118
Security Over Voltage,Over Current,Over Power,Over temperature ,Under Voltage,short-circuit,Emergency stop protection，Residual current detection ,surge protection,door Access,Grounding protection，Flame retardants
